Pd 1852 Heavy-Duty Professional Speaker 18 Inch PRO Audio Sound Sub Bass Subwoofer

Pd 1852 Heavy-Duty Professional Speaker 18 Inch PRO Audio Sound Sub Bass Subwoofer

Package size per unit product 500.00cm * 500.00cm * 240.00cm Gross weight per unit product 25.000kg PD 1852 Heavy-Duty P

Send your inquiry

DESCRIPTION

Basic Info
Model NO. HD/PD1852-2
Operation Mode Wire / Remote Control
Speaker System Optional Combination
Speaker Material Metal
Application Commercial, Stage, Theater, Live Show
Monitor None
THD 0.005%-0.01%
Sensitivity 97 dB
Voice Coil Diameter 125mm / 5 Inch
Voice Coil Material Copper
Basket Cast Aluminium
Frequency Range 41-2 K Hz
Type Subwoofer
Magnet 280mm Ferrite
Cone Paper Cone
Performance Stable
Samples Available
Product Pd 1852
Transport Package by Carton or as Your Requirement
Specification Net Weight: 23.5 KG
Trademark OEM and ODM are both welcome.
Origin China
HS Code 851829000
Production Capacity 6000pieces/Month
Packaging & Delivery
Package size per unit product 500.00cm * 500.00cm * 240.00cm Gross weight per unit product 25.000kg
Product Description
PD 1852 Heavy-Duty Professional Speaker 18 Inch Pro Audio Sound Sub Bass SubwooferProduct main features:- 18 inch PA speaker- High power- High performance- Accurate bass frequences- The premium choice for top of the range sub bass systems

Pd 1852 Heavy-Duty Professional Speaker 18 Inch PRO Audio Sound Sub Bass Subwoofer

Pd 1852 Heavy-Duty Professional Speaker 18 Inch PRO Audio Sound Sub Bass Subwoofer


Model:HD-PD1852/2
Specification
Nominal diameter 18mm/inch
Rated impedance 8ohm
Nominal power (AES) 1500W
Maximum power 3000W
Sensitivity (1w/1m) 97dB
Frequency response 42-2KHz
Voice coil diameter 125/5mm/ inch
Magnet Type Ferrite 280mm
T/S Parameter
Fs42Hz
Re5.6Ω
Qes0.38
Qts 0.37
Qms17.84
Vas64.6L
Cms128mm/N
Mms 415gr
BL41N/A
SD123.7M
Mounting information
Overall diameter 474mm
Bolt Circle diameter 459mm
Baffle Cutout diameter 415mm
Depth 190mm
Net weight 24.2KG
Shipping 500*500*240mm

INTRODUCTIONHengda Audio is a professinal speaker manufacturer with experience in the PA speaker field for 10years. We make different tranducers, compression drivers. We not only provide goods but technology. OEM and ODM are both welcome.
