Pd 1852 Heavy-Duty Professional Speaker 18 Inch PRO Audio Sound Sub Bass Subwoofer
Package size per unit product 500.00cm * 500.00cm * 240.00cm Gross weight per unit product 25.000kg PD 1852 Heavy-Duty P
Send your inquiryDESCRIPTION
Basic Info
Model NO. | HD/PD1852-2 |
Operation Mode | Wire / Remote Control |
Speaker System | Optional Combination |
Speaker Material | Metal |
Application | Commercial, Stage, Theater, Live Show |
Monitor | None |
THD | 0.005%-0.01% |
Sensitivity | 97 dB |
Voice Coil Diameter | 125mm / 5 Inch |
Voice Coil Material | Copper |
Basket | Cast Aluminium |
Frequency Range | 41-2 K Hz |
Type | Subwoofer |
Magnet | 280mm Ferrite |
Cone | Paper Cone |
Performance | Stable |
Samples | Available |
Product | Pd 1852 |
Transport Package | by Carton or as Your Requirement |
Specification | Net Weight: 23.5 KG |
Trademark | OEM and ODM are both welcome. |
Origin | China |
HS Code | 851829000 |
Production Capacity | 6000pieces/Month |
Packaging & Delivery
Package size per unit product 500.00cm * 500.00cm * 240.00cm Gross weight per unit product 25.000kgProduct Description
PD 1852 Heavy-Duty Professional Speaker 18 Inch Pro Audio Sound Sub Bass SubwooferProduct main features:- 18 inch PA speaker- High power- High performance- Accurate bass frequences- The premium choice for top of the range sub bass systemsModel:HD-PD1852/2 | ||
Specification | ||
Nominal diameter | 18 | mm/inch |
Rated impedance | 8 | ohm |
Nominal power (AES) | 1500 | W |
Maximum power | 3000 | W |
Sensitivity (1w/1m) | 97 | dB |
Frequency response | 42-2K | Hz |
Voice coil diameter | 125/5 | mm/ inch |
Magnet Type | Ferrite 280 | mm |
T/S Parameter | ||
Fs | 42 | Hz |
Re | 5.6 | Ω |
Qes | 0.38 | |
Qts | 0.37 | |
Qms | 17.84 | |
Vas | 64.6 | L |
Cms | 128 | mm/N |
Mms | 415 | gr |
BL | 41 | N/A |
SD | 123.7 | M |
Mounting information | ||
Overall diameter | 474 | mm |
Bolt Circle diameter | 459 | mm |
Baffle Cutout diameter | 415 | mm |
Depth | 190 | mm |
Net weight | 24.2 | KG |
Shipping | 500*500*240 | mm |
INTRODUCTIONHengda Audio is a professinal speaker manufacturer with experience in the PA speaker field for 10years. We make different tranducers, compression drivers. We not only provide goods but technology. OEM and ODM are both welcome.
