DESCRIPTION

Basic Info

Model NO.	HDE-680
Noise	<95dB
Hi-Fi	Not Hi-Fi
Activity	Passive
Operation Mode	Wire / Remote Control
Speaker System	Optional Combination
Speaker Material	Metal
Application	Commercial, Home, Line Array, Stage
Monitor	None
THD	0.005%-0.01%
Sensitivity	108
Frequency Range	800-18K Hz
Voice Coil Diameter	65mm /2.5 Inch
Coil Material	CCA
Diaphragm Material	Titanium
Magnet	Neodymium
AES Power Rating	100 W
Program Power	200W
Transport Package	Carton Box or as Your Requirement
Specification	B&C
Trademark	OEM and ODM are both welcome
Origin	China
HS Code	851829000
Production Capacity	5000 Pieces/Month

Product Description

Professional Speaker Pro Audio Titanium Compression Horn Driver Unit

General Specifications
Throat Diameter	36/1.4	mm/inch
Rated Impedance	8	ohm
Nominal Power handling	100	Watts
Program Power	200	Watts
Sensitivity(lw/lm)	108	dB
Frequency Range	800-18K	Hz
Minimum Impedance(Zmin)	5.6	ohm
Voice Coil Diameter	65/2.5	mm/inch
Winding Material	CCA
Diaphram Material	Titanium
Magnet Material	Neodymium
Mounting & Shipping Information
Overall Diameter	115	mm
Overall Depth	51	mm
Net Weight	1.8	KG
Multipack Size (4 in 1)	270*136*170	mm
Multipack Weight	7.9	KG

INTRODUCTIONHengda Audio is a professinal speaker manufacturer with experience in the PA speaker field for 10years. We make different tranducers, compression drivers. We not only provide goods but technology. OEM and ODM are both welcome.
